Plymouth Data Recovery — No.1 USB Stick & USB Flash Drive Specialists (25+ years)

Plymouth Data Recovery provides professional recovery for all USB flash drives (USB-A, USB-C, micro-USB OTG, dual-interface) and all fault types—from bent connectors and controller failures to deep chip-off NAND reconstructions. We work forensically: stabilise → acquire read-only clones/dumps → rebuild on the copy (never on your original). Free diagnostics with clear options before any paid work begins.

Top 20 USB Flash Drive Brands in the UK & Popular Lines

1. SanDisk — Ultra / Ultra Fit / Extreme Pro / iXpand / Dual Drive USB-C

2. Samsung — BAR Plus / FIT Plus / DUO Plus (USB-C↔A)

3. Kingston — DataTraveler Exodia/Max, DT Kyson, DT MicroDuo (OTG), IronKey (encrypted)

4. Lexar — JumpDrive S47/S80/S75, F35 (fingerprint)

5. PNY — Elite-X / Turbo / Pro Elite, Duo-Link (dual)

6. Integral — Neon / Courier / Crypto (FIPS) / UltimaPro

7. Transcend — JetFlash 790/920/930C, 890 (Type-C)

8. Corsair — Flash Voyager / Survivor (rugged) / GTX

9. ADATA — UV128/UV150, SE9, UE700 Pro, AI series

10. Patriot — Supersonic Rage / Magnum / Boost

11. Verbatim — Store ‘n’ Go / PinStripe / Metal Executive

12. TeamGroup — C186/C212, M211 OTG, PD series

13. Toshiba / KIOXIA — TransMemory U365/U301/U303

14. Sabrent — Rocket Nano (USB-C) enclosures/thumb SSDs

15. Silicon Power — Blaze / Touch / Jewel / Mobile C-series

16. Kingston IronKey — S1000/D300/D400 (HW-encrypted)

17. iStorage — datAshur PRO/Personal (PIN keypad, FIPS)

18. LaCie — Key/ItsaKey (legacy), USB-C mini SSDs

19. OWC — Envoy/Express (mini SSD thumb enclosures)

20. Intenso — Alu Line / Speed Line / Ultra Line

Memory card types we also handle (for comparison/combos with USB readers)

SD/SDHC/SDXC/SDUC, microSD family, CF/CFast/CFexpress, XQD, xD-Picture, Memory Stick, UFS Card. Popular card lines: SanDisk Extreme/Pro, Samsung PRO/Endurance, Kingston Canvas React Plus, Lexar Professional (1667x/2000x), Integral UltimaPro, PNY Elite/Elite-X, Transcend 700S/300S, Sony TOUGH, ProGrade V60/V90, Angelbird AV PRO.

(If your brand/model isn’t listed, we still recover it.)

How We Work (Forensic, Safe, Repeatable)

1. Intake & Triage — Identify controller family (Phison/SMI/Maxio/Alcor/Realtek/ChipsBank/etc.), NAND type (ONFI/Toggle, TLC/QLC), bridge/encryption, symptoms.

2. Stabilise & Acquire — If the stick enumerates, we forensic-image via a stable reader (UASP/BOT tuned). If not, we go monolith/chip-off to dump raw NAND (per-die, per-plane). All images/dumps are hash-verified.

3. Reconstruct the FTL — Decode ECC (BCH/LDPC), discover/extract XOR/scrambler, recover interleave (die/plane/channel), rebuild the translator (LBA↔PBA) to generate a raw disk image.

4. Logical Recovery (on the clone/image) — Repair exFAT/FAT32/NTFS/APFS/ext/XFS/ReFS: journal replay, directory rebuild, carving for large media (MP4/MOV/PST/DB).

5. Verification & Delivery — SHA-256/MD5 per-file, sample opens; return via encrypted drive or secure transfer.

Limits: Truly overwritten data and hardware-encrypted media without valid keys are not recoverable. We maximise outcome via journals, caches, prior versions, and partial recon.

Top 100 USB Stick / USB Flash Drive Faults — With Technical Recovery Methods

Format: Fault → Why it happens → Lab diagnosis & resolution (always on clones/raw dumps).

A) Connector / Mechanics (1–12)

1. Snapped USB-A plug → Shear stress → Rebuild pads/traces under scope; if inner layers torn, wire to test points; image.

2. Bent plug (intermittent) → Fatigued solder joints → Reflow/reball connector; swap socket; stabilise for long read.

3. USB-C shell crushed → Shorted CC/VBUS → Replace port/ESD array; verify Rp/Rd; image.

4. Loose connector shield → Poor ground → Re-terminate shield/ground; reduce EMI resets; image.

5. Sliding-cap strain cracked PCB → Micro-fractures → Micro-jumpers across trace; image.

6. Detachable OTG cap lost → Mis-insert damage → Inspect pads; replace connector; image.

7. Keyring tug cracked crystal → Clock instability → Replace XO (12/24/26 MHz typical); image.

8. Broken write-protect switch (rare) → WP stuck → Bypass WP pull; force RW/RO as needed; image.

9. Casing short → Shield contacting 5V → Insulate/repair; bench supply with current limit; image.

10. Dual-interface (A↔C) selector fault → Mux failure → Hard-wire to one path; image.

11. Micro-USB OTG plug snapped → Replace/uplink via adapter board; image.

12. Connector pads ripped off → No bus → Micro-wire to controller pins/test pads; image or go chip-off.

B) Power / Protection (13–24)

13. VBUS-to-GND short → Blown TVS/ESD arrays → Replace arrays; current-limit power; image.

14. LDO failure (3.3 V/1.8 V) → No core power → Replace LDO; check rails ripple; image else chip-off.

15. Polyfuse tripped → Over-current → Substitute bench supply; diagnose downstream short; image.

16. Over-voltage from hub → Controller damage → Rail rework; if MCU dead → chip-off.

17. Brownouts on spin-up → Insufficient bulk cap ESR → Replace bulk caps; soft-start; image.

18. Ground bounce on high-speed → CRC storms → Improve grounding, shorter cable, BOT mode; image.

19. Reverse current feeding host → Faulty bridge → Isolate VBUS; image on isolated reader.

20. Stuck 1.2 V core rail → PMIC latchup → Replace PMIC; image or chip-off.

21. ESD pin arrays open-circuit → Under-protection → Replace; stabilise link.

22. Burned transient suppressor → Permanent clamp → Remove/replace; verify rails; image.

23. Inrush surge kills host port → Negotiation fail → Current-limit bench PSU; image.

24. Cold joints on power nets → Intermittent resets → Reflow/reball; long imaging passes.

C) Controller / Firmware / Identity (25–42)

25. No enumerate (dead MCU) → Silicon failure → Board-level repair; else chip-off/dump NAND.

26. 0 MB capacity → Translator lost / config corrupt → Vendor loader; export raw, or chip-off; rebuild FTL.

27. Vendor “safe-mode” only → Boot ROM fallback → Enter MPTool/loader; pull raw; treat as disk image.

28. Wrong VID/PID (mass-prod mode) → Misflashed → Use factory tool to dump; avoid re-initialise; rebuild off-box.

29. Controller lock to RO → Firmware flag → RO imaging; full logical rebuild on clone.

30. Write-protect after errors → Threshold crossed → Force imaging path; never attempt writes.

31. Security/password set → FW lock → If user knows password, unlock, immediate image; else chip-off (if no encryption).

32. AES self-encryption enabled → Ciphertext at rest → Keys required; without keys, chip-off yields noise.

33. Stuck in test mode → Toggle pins asserted → Pull-down/up correction; normal enumerate; image.

34. MPTool “repair” attempted → Mapping wiped → Ignore repaired state; chip-off; reconstruct from raw.

35. Bad boot block → Boot loop → Patch loader in-circuit to extract LUN; else chip-off.

36. FTL journal lost (power-loss) → LBA map gone → Infer via OOB/page metadata; rebuild translator.

37. Garbage/XOR unknown → Scrambler not known → Crib-dragging (FAT/NTFS/APFS signatures) to derive XOR; apply; assemble.

38. Interleave unknown (multi-die) → Mis-ordered pages → Topology probe; test permutations against FS; select coherent map.

39. ECC profile mismatch → Wrong BCH/LDPC params → Syndrome analysis to pick correct decoder; re-read target regions.

40. Wear-levelling metadata wrap → Counter rollover → Temporal ordering; version fields to unwind.

41. Controller throttling loop → Thermal resets → Directed cooling; staged reads; merge best passes.

42. Dual-bank firmware split → Half updated → Force bank select; dump; or chip-off.

D) NAND / Monolith (43–62)

43. Retention loss (heat/time) → Threshold drift → Cold dump, voltage stepping, multi-read voting; ECC margining.

44. Read-disturb → Repeated reads upset neighbours → Lower Vref, idle between passes; prioritise weak blocks.

45. Program disturb → Adjacent cell upset → Discard high-syndrome pages; reconstruct from duplicates.

46. Bad block growth → Exceeded spare → Map & mask; fill gaps using FS context.

47. Die failure (partial) → Stuck CE/plane → Single-plane reads; merge; carve.

48. ONFI/Toggle mis-detect → Wrong mode → Force timings in reader; re-acquire.

49. SLC cache boundary loss → Mixed cache/TLC layout → Identify cache region via timing/OOB; temporal merge.

50. OP/hidden ranges omitted → Incomplete dump → Include reserved blocks; rebuild logical space first.

51. Short under NAND BGA → Bridged balls → Microsurgery reball; if still unstable → chip-off on donor carrier.

52. Package crack → Temperature cycling → Resin stabilise; low-temp dump.

53. Monolith unknown pinout → No standard padout → IR/X-ray or resistance mapping; wire D0-D7, CLE/ALE/RE/WE/CE/WP/RB/VCC/VSS; dump.

54. Monolith pad corrosion → Open circuits → Micro-abrasion, gold-wire; dump.

55. NAND ID spoofed → Vendor obfuscation → Read raw ID via low-level; set manual parameters; dump.

56. Toggle-mode skew → Interconnect delay → Per-channel timing sets; re-dump.

57. Multi-vendor NAND mix → Different ECC/XOR → Partition by die ID; decode per-group; merge.

58. Scrambler per-block changes → Rolling XOR → Detect per-range; apply dynamically.

59. OOB trimmed by reader → Lost spare metadata → Use raw-raw mode; re-capture; or infer from redundancy.

60. Erratic R/B# timing → Asynch ready → Scope tune delays; single-step reads.

61. Charge loss in cold → Below spec temp → Controlled warm window then dump; avoid further drift.

62. Over-erased blocks → Negative Vth → Selective retry, ECC relax; accept partials.

E) Logical / Partition / File System (63–85)

63. Accidental deletion → Directory entries unlinked → Bitmap/journal analysis; journal-aware undelete; carve slack/unallocated.

64. Quick format (exFAT/FAT32/NTFS) → Boot areas overwritten → Rebuild partition/boot sectors from backups; deep carve large media (MP4/PST).

65. Full format → Broad overwrite → Signature carving + heuristics; set expectations (partial).

66. MBR/GPT wiped → Disk “uninitialised” → Synthetic GPT from FS headers; mount RO.

67. exFAT bitmap corrupt → Allocation map wrong → Rebuild chain sets; recover orphans.

68. exFAT upcase loss → Name case table gone → Regenerate; restore structure.

69. FAT root dir damage → LFN/8.3 mismatch → Rebuild long/short chains; checksum validate.

70. NTFS $MFT damage → Lost file records → Replay $LogFile; rebuild $MFT/$MFTMirr; relink orphans.

71. NTFS runlist corruption → Fragment map broken → Heuristic run reconstruction; validate by file signatures.

72. ReFS object table issues → CoW mismatch → Export integrity-valid objects only.

73. APFS on USB (ToGo) → Omap/checkpoint issues → Walk checkpoints; rebuild omap; mount Data RO.

74. HFS+ catalog/extent B-trees → Tree damage → Rebuild; allocator-pattern carving.

75. ext4 superblock/inode loss → Use backup superblocks; offline fsck-like repair on image.

76. XFS log corrupt → Manual log replay; directory rebuild.

77. Camera/DCIM index corrupt → Container repair (MP4/MOV/MXF); stitch by PTS/offset.

78. Large 4K/8K footage fragmented → Non-contiguous extents → Range-map reconstruction; GOP-aware stitching.

79. RAW photo header loss → Rebuild IFD/headers; tile/strip merge (CR3/NEF/ARW).

80. VeraCrypt/TrueCrypt container header corrupt → Use backup header; if none, entropy-guided search; password required.

81. BitLocker-To-Go → Encrypted volume → Full image; decrypt with recovery key; export RO.

82. macOS Spotlight/temp writes post-incident → Overwrites → Roll back to earliest clone; avoid mounting original.

83. Windows chkdsk ran after crash → Second-order damage → Use pre-chkdsk clone; journal-aware rebuild; ignore destructive fixes.

84. Cloud sync deletions → Local metadata changed → Restore from versioning; carve temp caches.

85. Malware/autorun tampering → Hidden/locked → Forensic image; neutralise; recover clean files.

F) Host / Transfer / Protocol (86–93)

86. UASP driver bug → Random resets → Force BOT; QD=1; small-block reads; image.

87. USB hub under-power → Brownouts → Direct host port / powered hub; image.

88. Cable EMI/shield issue → CRC errors → Certified cable; clamp speed; image.

89. Reader firmware bug → Timeouts → Known-good lab readers; stable capture.

90. Auto-format prompt accepted → New FS laid down → Recover previous FS via backups/headers; carve.

91. MTP/PTP transfer aborted → Partial copies → Reimage raw; repair containers.

92. OS write-caching → Incomplete flush → Journal replay; recover pre-flush versions.

93. Disk signature collision → Mount confusion → Assign new signature on clone; mount RO.

G) Environmental / Handling (94–100)

94. Fresh water ingress → Ionic residue → Rinse/neutralise; dry; do not power; board repair or chip-off.

95. Salt water ingress → Rapid corrosion → Immediate neutralisation; short imaging window; priority passes.

96. Thermal bake in car → Retention drift → Cold dump; voltage stepping; multi-pass merge.

97. Freeze/thaw cycle → Condensation → Desiccate; warm-window dump; avoid reads at dew point.

98. Physical crush → PCB cracked → Micro-jumpers; if silicon compromised → chip-off.

99. Static discharge (ESD) → ESD arrays/MCU blown → Replace arrays; if MCU dead → chip-off.

100. Counterfeit capacity (hacked firmware) → Wraparound writes overwrite old data → Recover true addressable space; carve; integrity warning.

Professional Notes & Integrity

• Chip-off/monolith tools: PC-3000 Flash, Rusolut VNR, Flash Extractor; custom readers with adjustable Vref, timings, and CE muxing.

• ECC: BCH/LDPC detection by syndrome analysis; per-die settings; XOR/scrambler discovery via cribbing (FAT/NTFS/APFS signatures).

• Validation: Image/dump hashing; per-file checksums; app-level opens for key artefacts (databases/video/photos).
